Main technical parameters:
Working width: 3 m
Matching power: 200-220 HP
Working speed: 7-10 km/h
Number of rows: up to 20 rows, adjustable
Row spacing: from 15 cm, adjustable according to operational requirements
Sowing depth: 0-50 mm, adjustable
Tillage depth: 5-20 cm
Seed tank volume: 500 L
Fertilizer tank volume: 700 L (double fertilizer tank)
PTO speed: 1000 r/min
Seed discharge drive: electric drive
Seed feeding mode: pneumatic conveying
Fans: Double electric fans
Speed measurement: radar speed measurement
Control mode: Intelligent electronic control system + tablet terminal
Profiling mechanism: Parallel four-link mechanism
Main functions:
Support electronic adjustment of seeding volume, radar speed measurement, real-time display of operating parameters and monitoring of seeding status, and can replace seed discharge components according to different crops and operating conditions.
Small seed sowing configuration:
It can be equipped with optional small seed sowing operation device, which is suitable for alfalfa, grass mignonette and other small seed crops. According to different crops, agronomic requirements and the actual needs of customers to configure the corresponding seed discharge system, delivery system, control system and operating components.
Optional configuration:
GPS positioning system, seed discharge tube monitoring system, material level monitoring system, seeding status monitoring, seed discharge wheels of different specifications and other seeding accessories.
Customization instructions:
Equipment configuration can be selected and adjusted according to different crops, operating conditions and customer technical requirements, the specific configuration is subject to the technical agreement and supply contract confirmed by both parties.
