| Model | 4LZ-7.0 | |
| Structural Type | Tracked, Self-Propelled, Full-Feeding Type | |
| Overall Dimensions (Operating State) | Length (mm) | 5840/5840 |
| Width (mm) | 2520/2520 | |
| Height (mm) | 3010/2950 | |
| Overall Machine Weight (kg) | 3680/3480 | |
| engine | Model | 4G33V16 |
| Type | Vertical, Inline, Water-cooled, Four-stroke | |
| Power (kW) | 92 | |
| Rated Speed (r/min) | 2600 | |
| Fuel Tank Capacity (L) | 200 | |
| Transmission | World-manufactured 85 Transmission | |
| Cab | Plastic-steel Canopy / Deluxe Air-conditioned Cab | |
| Running Part | Track Specifications (Pitch × Links × Width) | 90 mm × 56Links × 500 mm (Standard) |
| Track Gauge (mm) | 1250 | |
| Minimum Ground Clearance (mm) | 320 | |
| Harvest Part | Header Width (m) | 2.2 |
| Feeding Capacity (kg/s) | 6 | |
| Header Lift Mechanism | Hydraulic | |
| Threshing Section | Threshing Method | Longitudinal Axial-Flow Cylinder |
| Threshing Cylinder Dimensions (mm) | Ф620 × 2210 | |
| Controls: | The 45cc Hydrostatic Transmission (HST) ensures faster speeds within the same gear compared to competing products. | |
| Cleaning Section: | Vibrating Screen + Centrifugal Fan | |
| Granary Section | Grain Unloading Method | 360° Extended Rotating Unloading (Optional: One-Touch Return) |
| Grain Tank Capacity (m³) | 1.8 | |
| Operating Efficiency | 2.85–15 mu/hour | |
| Suitable Crops | Rice, Wheat, Rapeseed, Grain Corn, Soybeans, Millet, Buckwheat | |
