Product Features: This agricultural trailer is compatible with various 18-24hp tractors in China and is primarily used for light-duty transportation. It features a simple and rational structure with flexible operation.
Towing Configuration: Triangular frame towing.
Surface Treatment: Large shot blasting machine to eliminate welding stress, remove rust, remove oxide scale, apply anti-rust paint, topcoat, and bake-cure coating.
Welding Process: CO2 fixture welding.
Transportation Form: Loose parts transportation, boxed soft packaging.
This vehicle is designed for rice harvesting.
1. Features standard rear unloading functionality.
2. Tyres are steel-cord tyres with high load capacity and durability, suitable for both high and low speeds.
3. Low loading surface with support legs at the rear of the trailer, suitable for loading and unloading with Kubota transporters.
4. All dimensions are designed according to the actual dimensions of Kubota series harvesters.
5. Box panel design is more user-friendly, allowing one person to remove and install it.
Carriage Size（MM） | 3600*2200*550 |
load（KG） | 3000 |
Specification of tire | 10.0/75-15.3-16PR TL |
Brake form | Air brake |
Matched power | 18-24HP |
Out dimension（MM） | 4500*2300*1200 |
Structure weight（KG） | 1200 |
Unload form: | Hydraulic dump truck |
40 ' HQ | 24 sets |
