Model | 2ZGQ-6D1(SPV-6CMD)(G4) | |||
Overall dimensions in transport mode (length × width × height) mm | 3090×2220×2580 | |||
Overall dimensions in operating mode (length × width × height) mm | 3090×2245×2580 | |||
Overall machine dimensions (length × width × height) mm | 3090×2245×2580 | |||
Structural mass (kg) | 805 | |||
Engine | Total displacement (L) | 0.778 | ||
Rated power (kW) | 14.2 | |||
Fuel tank capacity (L) | 34 | |||
Running gear | Transmission Type | Hydrostatic Transmission (HST) | ||
Number of Gears | Main transmission: Infinitely variable forward/reverse (Sub-transmission: 2 speeds; Anti-bogging transmission: 2 speeds) | |||
Minimum ground clearance (mm) | 500 | |||
Rice-Transplanting Section | Number of working rows | 6 | ||
Row spacing (mm) | 300 | |||
Hole spacing (mm) | (*1)100、120、140、160、180、210、240 | |||
Number of seedlings per cell | Number of lateral seedling picking passes (times) | 26、20、18、14(*2) | ||
Adjustment amount | Longitudinal seedling picking depth (mm) | 8～18 | ||
Balancing mechanism type | Mechanical | |||
Seedling height (mm) | 80～250 | |||
Leaf age (leaves) | 2.0～4.5 | |||
Hourly operational productivity (hm²/h) | (*1)0.2～0.42 | |||
others | Marking rod | Standard equipment | ||
Seedling preparation rack | Standard equipment | |||
